3. Console Monitor Indications (Please refer to page 24, as for LED indications.)
No LCD
Monitor
Indications
Unit Remarks
00 Fout Output frequency Hz
01 Fref
Reference
frequency
Hz
02 Iout Output current A
03 Vout Output voltage V
04 Torq out
Torque (torque
current)
% Current for the same phase as the output voltage is indicated.
05 Vdc DC voltage V
06 Motor Speed
Synchronous
motor RPM
rpm
For ASR operation, number of rotations is indicated. For other
operations, frequency obtained based on the number is indicated.
07 OL counter Overload counter %
When the rated motor current is exceeded, the counter starts
counting. After this, when the counter reaches 100%, the overload
protection starts. (When OL.Set=100%)
08 Line Speed Line speed --- Value obtained in code No.93 is indicated.
09 I1 term check
Input terminal
check 1
bit on:1. Meaning of each bit is shown in Table 7
10 I2 term check
Input terminal
check 2
bit on:1. Meaning of each bit is shown in Table 7
11 O-term check
Output terminal
check
bit on:1. Meaning of each bit is shown in Table 7
12 --- Not used
13 --- Not used
14 --- Not used
15 ROM Version ROM version
The XX-XX portion of the ROM software version VF61-XX-XX is
indicated. Alphabetic characters A, B, ..., however, are converted
to 0, 1, ...
16 Special moni
Adjusting monitor
for internal use
17 Trouble moni Trouble history
The contents of the last five troubles and the current and voltage
at the time of the troubles are indicated.
Table 6 Monitor Indications.
Input terminal check 1
I1 term check
Input terminal check 2
I2 term check
Output terminal check
O-Term check
Table 7 Terminal check bits
Terminal no.
17 :STARTF
19 :STARTR
20 :JOG-F
21 :JOG-R
23 :RESET
not used
Terminal no.
24 :M-IN-1
25 :M-IN-2
26 :M-IN-3
27 :M-IN-4
28 :M-IN-5
29 :M-IN-6
Terminal no.
11 :M-0-1
13 :M-0-2
15 :M-0-3
16 :M-0-4
1-2 :52MA
3-4-5 :86A
