4-4 Optional Setting Items (Option)
When Option is selected at code No. 16 (selection of special setting items) in the basic setting items, the func-
tions for the following code numbers 17-24 are set.
Even when code No. 16 is already set to Option, select Option again to set those code numbers.
When the optional PC board is mounted, set the output items from among the
following.
For details, see the instruction manual attached to the optional board.
No. Code No. LCD Setting
1
No. 17 4-20out.Sel 4-20mA output selection
No. Selection item No. Selection item
1 Vout Output voltage 5 Fout Output frequency
2 Iout Ouput frequency 6
Internal Mon (Adjusting monitor for
internal use)
3 Torq Torque
2 No. 18 4-20out.Gain 4-20mA output gain
3 No. 19 4-20outOfset 4-20mA output offset
4 No. 20 ISOin.Gain Insulation input gain
5 No. 21 ISOin.Ofset Insulation input offset
6 No. 22 PG-Pulse Number of PG pulses
7 No. 23 ASR.P-Gain
ASR proportional gain (adjusted for
speed control)
8 No. 24 ASR.I-Time
ASR integral time (adjusted for speed
control)
Table 19 Optional setting code
