13
8.4 Indications setting
The LC-171 has two types of indicators:
1. LED
2. Buzzer
The installer can adjust both indicators operation during detection (ON or OFF) by using
switch number “1” for the buzzer and switch number “2” for the LED. When the LED indicator
is ON the LED indicator will activate for 1 second each time an intrusion is detected. When the
LED indicator is OFF the LED will not be used to indicate an intrusion has occurred.
When the Buzzer indicator is ON the Buzzer will activate for 1.8sec each time an intrusion is
detected. When the Buzzer indicator is OFF the buzzer will not be used to indicate an intrusion
has occurred. (Setting the buzzer ON gives the installer the ability to have audible
confirmation of intrusion detection during the adjustments and a walk test. After completing
adjustments and walk testing it is recommended to switch the buzzer OFF)
! Place the top cover to the base and close it using the bottom screw.
LED OFF
ON
OFF
Buzzer ON
ON
OFF
Factory default setting
Factory default setting
EN
