LCD5500 Controls and Display
Keypad
Press keys as prompted by the
LCD display to view alarms or
troubles, to Arm/Disarm the
system or to shunt zones.
To exit/return press
[#]
To select function press [
*
]
#
Press to Exit / Return.
TEST SYSTEM WEEKLY
Refer
to
Instruction
Manual for testing
I
Function Keys
allow easy
single button activation of the
1
most commonly used features
Important Note
Test system weekly, have
system trouble conditions
corrected by installer.
Liquid Crystal Display
(LCD)
1
displays prompts and system
information on two 16
character lines.
If
"<
>"
appears, it indicates
that more information is
available. Press either key to
view.
Press [<] to see the previous
function or item of information.
Press [>] to advance the
display to next function or
item of information.
Press both
4
Keys for 2
seconds to send a Fire
transmission.
Note: The Fire, Auxiliary and
Panic keys will
NOT function
unless programmed by the
Installer. if these keys are in
service and the installer has
enabled audible feedback,
holding down the key for 2
seconds will cause the keypad
sounder to beep indicating that
the input has been accepted
and transmission is underway.
8
