Ratings Compatibility
Table 1: Communicator Ratings
Model
3G2080(R)E
Cellular only
TL280(R)E
Internet only
TL2803G(R)E
Internet and Cellular
Power Supply Ratings
Input Voltage
10.8-12.5 VDC
Power is supplied from the panel’s PC-Link header or a PCL-422 module in remote cabinet
installations. In remote cabinet installations,the PCL-422 module located with the communicator is
powered by either an HSM2204 or an HSM2300. Refer to the PCL-422 installation instructions for
details.
Current Consumption
Standby Current 90mA @ 13.66V 120mA @ 13.66V
Alarm (Transmitting)
Current
400mA @ 12V
Operating Frequency Depends on model (refer to Model Information on page 3)
Typical Antenna Gain 2dBi
Environmental Specifications
Operating Temperature -10°C to 55°C
Humidity 5% ~ 93% relative humidity, non-condensing
Mechanical Specifications
Board Dimensions (mm) 100 × 150 × 15 100 × 150 × 15
Weight (grams) with
bracket
310 320
Table 2: Compatible Receivers and Panels
Communicator Receiver/Panel Description
3G2080(R)E Receiver
l Sur-Gard System I-IP Receiver, version 1.13+
l Sur-Gard System II Receiver, version 2.10+
l Sur-Gard SG-DRL3-IP, version 2.30+ (for Sur-Gard System III Receiver)
l Sur-Gard SG-DRL4-IP version 1.20+ (for Sur-Gard System IV Receiver)
l Sur-Gard SG-DRL5-IP version 1.00+ (for Sur-Gard System 5 Receiver)
TL2803G(R)E Panel
l HS2016
l HS2016-4
l HS2032
l HS2064
l HS2128
NOTE: Enter [*][8][Installer Code][900] at keypad to view the panel version number.
Pre Installation Configuration
Encryption
The communicator uses 128 Bit AES encryption. Encryption can only be enabled from the monitoring station receiver. Each
receiver (Ethernet 1 and 2, cellular 1 and 2) can independently have encryption enabled or disabled. When encryption is
enabled, the central station will configure the device to encrypt communications the next time the communicator module per-
forms a communication to that receiver.
NOTE: Packets will start being encrypted only after the next event is sent to that receiver, or if the unit is restarted.
Before leaving the installation site, the communicator TL2803G(R)E Ethernet line shall be connected via an APPROVED
(acceptable to the local authorities) Network Interface Device (NID). All wiring shall be performed according to the local
electrical codes.
