P r ogram De scriptions: 5.1 1 PGM Outpu t Options
21
NOTE: Only ONE of options [03] Sensor Reset, [04] 2-wire
smoke, and [20] [*][7][2] Command Output Option #2 may be
programmed on the same system.
[04] 2-wire smoke (PGM2 only)
When this option is selected, the PGM functions much like
option [03] in that it is a normally low output supplying the
negative return. However, 2-wire smoke detectors can be sup-
ported, meaning that a zone input need not be used. The 2-
wire smoke detector input is an instant and latching alarm.
This input does not follow Swinger Shutdown.
NOTE: For the 2-wire smoke option to work, connector JP1
must be removed from the PC1555 control board.
NOTE: 2-Wire smoke detectors use PGM2 as a supervised
input with a 2200
Ω
end-of-line resistor. A trouble condition will
be generated if an open condition is detected between PGM2
and Aux+ .
NOTE: For option [04], 2-wire smoke, do not change the PGM
Output Attributes from the default settings.
[05] Armed Status
When the system is armed, the PGM output will activate at the
beginning of the exit delay. The output deactivates when the
system is disarmed.
[06] Ready To Arm
The PGM will be active as long as the system is ready to arm
and all non-force armable zones on the system are restored.
Once an access code is entered to arm the system and the
exit delay begins, the PGM output is deactivated.
[07] Keypad Buzzer Follower Mode
The PGM will activate when any of the following events occur
and will remain active for as long as the keypad buzzer is
active:
• Door Chime • Entry Delay
• Auto-Arm Prealert • Audible Exit Delay
• 24 Hour Supervisory Buzzer Zone
[08] Courtesy Pulse
Upon arming, the PGM output will activate for the duration of
the exit delay plus an additional two minutes. Upon disarming,
the PGM output will activate for the duration of the entry delay
plus an additional two minutes.
[09] System Trouble Output
The PGM output will activate when any of the selected trouble
conditions are present. It will deactivate when all the selected
trouble conditions are cleared.
The PGM attributes for this option, programmed in Sections
[141] to [142], differ from the standard selection of attributes.
Program which trouble conditions will activate the output by
selecting some or all of the following attributes:
Attribute
[1] ..........Service Required (battery, bell, general trouble,
general tamper, general supervisory)
[2] ..........AC Failure
[3] ..........Telephone Line Trouble
[4] ..........Failure to Communicate
[5] ..........Fire Trouble / Zone Fault
[6] ..........Zone Tamper
[7] ..........Zone Low Battery
[8] ..........Loss of Clock
[10] System Event (Strobe Output)
The output activates when any of the selected system events
(alarms) occur on the system.
NOTE:This output will activate for silent and audible alarms or
medical conditions only. It will not activate during pre-alert or
delays.
If attribute [8] is turned ON, the output will activate for the
number of seconds programmed in the PGM output timer
(section [164]).
If attribute [8] is turned OFF, in the armed state, the output will
deactivate only once the system is disarmed. If an alarm acti-
vates this output in the disarmed state, the output will deacti-
vate if a user enters a valid access code while the Bell Cut-off
timer is counting down. The output will also deactivate if
someone arms the system after the Bell Cut-off has expired.
This output can be used to indicate that an alarm has
occurred before entering the premises.
The PGM attributes for this option, programmed in Sections
[141] to [142], differ from the standard selection of attributes.
Program which events will activate the output by selecting
some or all of the following attributes:
Attribute
[1].........Burglary (Delay, Instant, Interior, Stay/Away and
24 Hour Burglary Zones)
[2].........Fire (Fire Keys, Fire Zones)
[3].........Panic (Panic Keys and Panic Zones)
[4].........Medical (Auxiliary Keys, Medical and Emergency
Zones)
[5].........Supervisory (Supervisory, Freezer and Water
Zones)
[6].........Priority (Gas, Heat, Sprinkler and 24 Hour Latch-
ing Zones)
[7].........Holdup (Holdup zones)
[8].........Output Follows Timer (output will activate for the
number of seconds programmed in the PGM Out-
put Timer) / Output Latched
NOTE:If attribute [8] is turned ON, attributes [1-7] must also be
turned ON.
PGM Output Timer. . . . . . . . . . . . . . . . . . . . . . .Section [164]
[11] System Tamper (All Sources)
The PGM output will activate when any tamper condition is
present and will deactivate when all tampers are restored.
[12] TLM and Alarm
The PGM output activates when the system experiences both
a telephone line trouble and an alarm. When the system is
armed, the output will deactivate only if an access code is
entered or if the telephone line is restored.
If an alarm activates this output in the disarmed state, the out-
put will deactivate if a user enters a valid access code while
the Bell Cut-off timer is counting down, or if the telephone line
is restored. The output will also deactivate if someone arms
the system after the Bell Cut-off has expired.
NOTE:This output will activate for all silent and audible alarms
except the Duress alarm and 24-hr PGM inputs.
[13] Kissoff Output
The output will activate for two seconds after the control panel
receives the kissoff transmission from the central station.
