PowerSeries - PC1616/PC1832/PC1864
16
Section [165] Maximum Dialing Attempts
Program the Maximum Dialing Attempts before the panel will generate a Failure to Communicate (FTC) trouble condition.
Valid entries are [001] to [005]. For UL Listed installations, 5 attempts is required.
Section [166] Post Dial Wait for Handshake
Program the maximum time the panel will wait, after dialing, for a valid handshake from the central station.
Valid entries are [001] to [255] seconds.
Section [167] T-Link Communications Wait for Acknowledgement
Program the maximum time the panel will wait, after sending a data packet, for an acknowledgement from the central station.
Valid entries are [001] to [255] seconds.
Section [168] Daylight Savings Time (Move Clock Ahead)
Program the 3-digit Month (Data [001] to [012] represents January to December), the 3-digit Week (Data [000] represents day of the month,
Data [001] to [005] represents weeks 1 to 5 of the month), the 3-digit Day (Data [001] to [031] represents day of the month if [000] was pro-
grammed in Day of the Month entry, IF [001] to [005] was programmed then Data [001] to [007] represents Sunday to Saturday), the 3-digit
Hr to initiate the change (Data [000] or [023] represents the hour to make the change) and the Increment (Data [001] or [002] represents the
number of hours to adjust).
Section [169] Standard Time (Set Clock Back)
Program the 3-digit Month (Data [001] to [012] represents January to December), the 3-digit Week (Data [000] represents day of the month,
Data [001] to [005] represents weeks 1 to 5 of the month), the 3-digit Day (Data [001] to [031] represents day of the month if [000] was pro-
grammed in Day of the Month entry, IF [001] to [005] was programmed then Data [001] to [007] represents Sunday to Saturday), the 3-digit
Hr to initiate the change (Data [000] or [023] represents the hour to make the change) and the Increment (Data [001] or [002] represents the
number of hours to adjust).
Section [170] PGM Output Timer
Program the time, in seconds, PGM outputs programmed to follow the PGM Output Timer will activate for. Valid entries are [001] to [255].
Section [173] Bell Delay Timer
Program the time, in minutes, the panel will delay activating the bell output when an alarm occurs. If a TLM trouble condition is detected,
the Bell Delay Timer will be aborted. Valid entries are [001] to [255].
[4]
ON: the user can manually bypass the zone using the [
][1] command. OFF: the zone cannot be manually bypassed.
[5] ON: the partition can be armed even if the zone is violated (the zone will not affect the Ready status). OFF: the zone must be secure
before arming.
[6] ON: the system shuts down alarm reporting after the programmed number of alarms have occurred. OFF: the panel will always
report the event if an alarm occurs.
[7] ON: the system delays reporting the event for the time programmed for the Transmission Delay time. OFF: the panel immediately
transmits the reporting event when an alarm is detected.
[8] ON: the zone is either a wireless or addressable device. OFF: the zone is a hardwire zone (main panel, zone expander or keypad
zone).
[9] ON: the zone has the Cross Zone feature enabled. OFF: the zone functions normally.
When Zone Types (Section [001] to [004]) are programmed, the system will change the Zone Attributes to those found in the chart
included in the Programming Worksheets. The Zone Attributes will default if a new Zone Type is programmed for a specific zone.
After programming the Zone Types, enter Section [101] to [164] and ensure that all options are programmed correctly.
Ready light ON: Program attributes [1-8]
Ready light and Armed light ON: Program attribute [9] (press [1] to turn option ON or OFF)
Press [9] to switch between attributes [1-8] and attribute [9].
