PowerSeries - PC1616/PC1832/PC1864
32
[101]-[164] Zone Attributes
Zone Attribute Defaults (Y = Option ON; N = Option OFF): Bold entries are opposite for SIA CP-01
* For UL installations, do not change attribute 5 (Force Arming) from the default setting.
Section Zone # Zone Audible/ Steady/ Chime Bypass Force* Swing Tx. Delay Wireless Cross Zn
Type** Silent Pulsed No No No No No No No
12345 6789
[101] 01 ( ) I________I I________| I________| I________| I________| I________| I________| I________I I________|
[102] 02 ( ) I________I I________| I________| I________| I________| I________| I________| I________I I________I
[103] 03 ( ) I________I I________| I________| I________| I________| I________| I________| I________I I________I
[104] 04 ( ) I________I I________| I________| I________| I________| I________| I________| I________I I________I
[105] 05 ( ) I________I I________| I________| I________| I________| I________| I________| I________I I________I
[106] 06 ( ) I________I I________| I________| I________| I________| I________| I________| I________I I________I
[107] 07 ( ) I________I I________| I________| I________| I________| I________| I________| I________I I________I
[108] 08 ( ) I________I I________| I________| I________| I________| I________| I________| I________I I________I
[109] 09 ( ) I________I I________| I________| I________| I________| I________| I________| I________I I________I
[110] 10 ( ) I________I I________| I________| I________| I________| I________| I________| I________I I________I
[111] 11 ( ) I________I I________| I________| I________| I________| I________| I________| I________I I________I
[112] 12 ( ) I________I I________| I________| I________| I________| I________| I________| I________I I________I
[113] 13 ( ) I________I I________| I________| I________| I________| I________| I________| I________I I________I
[114] 14 ( ) I________I I________| I________| I________| I________| I________| I________| I________I I________I
[115] 15 ( ) I________I I________| I________| I________| I________| I________| I________| I________I I________I
[116] 16 ( ) I________I I________| I________| I________| I________| I________| I________| I________I I________I
Attribute: 123456 789
ON Audible Steady Chime Bypass Force* Swing Tx. Delay Wireless Zn Cross Zn
OFF Silent Pulsed No No No No No No No
Zone Type:
00 Null Zone NNNNNNNNN
01 Delay 1 YYYYNYN NN
02 Delay 2 YYYYNYN NN
03 Instant YYYYNYN NN
04 Interior Y Y N Y N Y N NN
05 Int. Stay/Away Y Y N Y Y Y N NN
06 Dly. Stay/Away Y Y N Y Y Y N NN
07 Dly. 24hr Fire (Hardw.)YNNNNNNNN
08 Stand. 24hr Fire (Hardw.) Y N NNNNNNN
09 24hr Superv. N Y N N Y NNNN
10 24hr Superv. Buzzer N Y N Y N NNNN
11 24hr Burglary Y Y N Y N NNNN
12 24hr Holdup N Y N N N NNNN
13 24hr Gas Y N N N N NNNN
14 24hr Heating Y N N N N NNNN
15 24hr Medical Y Y N N N NNNN
16 24hr Panic Y Y N N N NNNN
17 24hr Emergency Y Y N N N NNNN
18 24hr Sprinkler Y Y N N N NNNN
19 24hr Water Y Y N N N NNNN
20 24hr Freeze Y Y N N N NNNN
21 24hr Latching Tamper Y Y N N N NNNN
22 Momentary Keyswitch N N N N Y N N N N
23 Maintained Keyswitch N N N N Y N N N N
25 Interior Delay Y Y N Y N Y N NN
26 24hr Non-alarm N N N N Y N N N N
29 Auto Verified Fire YNNNNNNNN
30 Fire Supervisory NNNNNNNNN
31 Day Zone YYNYYYYNN
32 Instant Stay/Away Y Y N Y N NNNN
35 24 hr Bell/Buzzer Y Y N Y N Y N NN
37 Night Zone Y Y N Y Y Y N NN
87 Dly. 24hr Fire (Wireless)YNNNNNNY N
88 Stand. 24hr Fire (Wireless) Y N NNNNNY N
