9
The Liquid Crystal Display (LCD) displays
prompts and system information on two 16
character lines.
If “< >” appears, more information can be
accessed by using the arrow (< >) keys. Press [<]
to see the previous function or item of information.
Press [>] to advance the display to next function
or item of information.
Press the keys on the number pad as prompted
by the LCD display to view alarms or troubles, to
arm and disarm the system and to bypass zones.
To exit a function and return to the Ready state,
press [#].
To select a function press [
✱].
LCD5500Z Keypad
Emergency Keys (All Keypads)
Press both * Keys for two seconds to send a
FIRE transmission.
Press both
* Keys for two seconds to send an
AUXILIARY transmission.
Press both * Keys for two seconds to send a
PANIC transmission.
* IMPORTANT NOTE (All Keypads): The Fire,
Auxiliary and Panic keys will NOT function
unless programmed by the installer. If these
keys are in service and the installer has enabled
audible feedback, holding down the key for two
seconds will cause the keypad sounder to beep
indicating that the input has been accepted and
transmission is underway.
Important Note: Test system weekly and have any system trouble conditions
corrected by your alarm installer.
LCD5501Z Keypad
