Table 16: Network Indicator - Digit 3
Network Indicator Value Means
OFF No network trouble
ON
Ethernet cable disconnected
Ethernet DHCP failed
Flashing
Incoming transmission
Outgoing transmission
Incoming transmission
[985] Radio Initialization Status
The radio initialization status provides installers with the status of radio communication. It is displayed as an 8-digit toggle
option, with each digit indicating a task in the initialization process.
1.
Radio power up
2.
Received the SMS from C24 Communications (North America only)
3.
Radio reset
4.
Radio attached to network
5.
Receiver 1 initialized
6.
Receiver 2 initialized
7.
Receiver 3 initialized
8.
Receiver 4 initialized
For example, the radio initialization status code 12-45--- indicates that radio has been powered up, it has received SMS sig-
nal from C24 Communications, the radio is attached to the network, and receiver 1 has been initialized. This code would
update to 12-45678 when receivers 2, 3, and 4 are initialized.
If the radio initialization status code does not indicate any problems, proceed with installation as per this manual. If troubles
are reported, reset the initialization process. If this does not fix the problem, refer to the troubleshooting section in this
manual. The following table shows each digit position in the status code, each digit’s value and its assigned meaning in the
eight-digit code:
Table 17: Radio Initialization Status - 1-8 bits completion
Bit 1 2 3 4 5 6 7 8
Not Completed - - - - - - - -
Completed 1 2 3 4 5 6 7 8
[987] Language Version
This section will display the current language version of the communicator.
[988] DNS 1 IP Address
This section will display the IP address of DNS Server 1. This is useful when the unit is configured for DHCP and the IP
address assigned to the device by the DHCP Server is needed. This value is programmed in Section [007] or assigned by
DHCP.
[989] DNS 2 IP Address
This section will display the IP address of DNS Server 2. This is useful when the unit is configured for DHCP and the IP
address assigned to the device by the DHCP Server is needed. This value is programmed in section [008] or assigned by
DHCP.
[990] Boot Loader Version
This section will display the current boot loader version of the communicator.
[991] Communicator Firmware Version
This section will display the current firmware version of the device. Update worksheets with new version after a flash update
is completed.
[992] Ethernet IP Address
This section will display the IP address of the Ethernet connection. This value is programmed in section [001] or assigned by
DHCP.
