D3. Understanding the Scancom Reporting Protocol Data Format
The SCANCOM data format consists of
13 decimal digits divided into 4 groups,
from left to right, as shown on the right.
Each channel is associated with a
specific event as follows:
1
st
"C": Fire
2
nd
"C": Personal attack
3
rd
"C": Intruder
4
th
"C": Open/close
5
th
"C": Alarm cancel
6
th
"C": Emergency
7
th
"C": Second alarm
8
th
"C": Trouble messages
System Status:
no trouble, test,
low battery
The digit in this position
conveys the status of
channel 1
The digit in this position
conveys the status of
channel 8
D4. SIA over IP - Offset for Device User
System tamper would report as 000
Zone 5 would report as 005
Keyfob/User number 101 would report
601
Pendant number 1 would report 651
Keypad number 8 would report 708
Siren number 9 would report 809
Repeater number 4 would report 834
Expanders/Bus
devices/PGM
Device number 2 would report 852
Troubles for:
GSM
BBA
Plink
Guard
GSM module network fail 876
BBA bus trouble 877
