DSPM Defender 3 - System Handling and Installation; Transportation and Inspection; Location and Placement

4.2.1. Upon receipt inspect the container and pallet for shipping damage. If there was any dam-age during trans-
portation; Do Not turn on the unit. Immediately notify the shipping agent/ transportation carrier and DSPM. If no
damage is evident, move the packed DSPM UPS to Its Installation location.
The packaging is recyclable; keep it for reuse or
please disposed of it.
4.2.2. Using care to avoid puncturing the shipping material with any sharp objects. which would damage the con-
tents. open the shipping material by carefully removing any banding and shipping material from the sides, ends and
top.
4.2.3. Remove the packing and vapor barrier and inspect the equipment for any obvious shipping damage. It Is
recommended that the units not be loosened from the shipping pallet until after all handling by forklift or pallet jack
is completed.
4.2.4. Immediately le a claim with the shipping agency if any damage, as a result of shipping. is observed.
4.2.5. Follow these steps to inspect all surfaces for abrasions and dents:
4.3.1. Before starting, check the load tolerance of the oor and verify that the oor will be able to support the UPS at
its nal destination and the route to get it there. After verifying the weights verify that when the unit is placed in its
nal position that the minimum clearances required have been met. Install the Emergency Lighting Inverter System
in a protected area with adequate airow and free from excessive dust. Do not operate the Emergency Lighting
Inverter System where the temperature and humidity is out of the specied limits.
4. TRANSPORTATION, INSPECTION, AND INSTALLATION
4.1. HOW TO TRANSPORT THE SYSTEM
Note: Do not transport in a horizontal position. Cabinets should be maintained uptight within +/- 15’ of the vertical
during handling.
4.2. INSPECTION
4.3. LOCATION AND PLACEMENT
4.2.5.1. Open the front door of the cabinet.
4.2.5.2. Verify that all the transformers, inductors. electrical, and electronic devices are rmty mounted.
4.2.5.3. Verify that the transformer coils and terminal lugs are free of contact with any grounded metal surface
and that the transformer terminal wires are securely connected.
4.2.5.4. Verify that the internal Wiring is not damaged.
4.2.5.5. Verify that all wires to and from the output lter assembly, input lter assembly. inverter assembly, and
bypass switch are securely connected.
4.2.5.6. Verify that the circuit breakers are rmly seated and that the wires are securely connected.
4.2.5.7. Inspect all batteries for damage (cracks. leaks. loose connections. etc..)
4.2.5.8. Reinstall all panels, covers and close all doors.
