• 7 •
3. If necessary, press the BATTERY
TYPE button until the correct type is
indicated.
4. Read the voltage on the digital display.
Keep in mind that this reading is only
a battery voltage reading; a false
surface charge may mislead you.
Power-Up Idle Time Limit
If no button is pressed within 10 minutes
after the battery charger is rst powered
up, the charger will automatically switch
from tester to charger if a battery is
connected. In that case, the charger will
be set to charge at the maintain mode
and gel cell battery type.
Testing After Charging
After the unit has been changed from
tester to charger (by selecting a charge
rate), it remains a charger. To change the
battery charger back to a tester, press the
CHARGE RATE button until all charge
rate LEDs are off.
Fan
The charger is designed to control its
cooling fan for efcient operation. It is
normal for the fan to start and stop when
maintaining a fully charged battery.
Keep the area near the charger free of
obstructions to allow the fan to operate
efciently.
10. CALCULATING CHARGE TIME
BATTERY PERCENT AND CHARGE TIME
This charger adjusts the charging time in
order to charge the battery completely,
efciently and safely. The microprocessor
automatically performs the necessary
functions. This section includes guidelines
that can be used to estimate charging
times. Use the following table to determine
the time it will take to bring a battery to full
charge. First, identify where your battery
ts into the chart.
CCA = Cold Cranking Amps
Ah = Amp Hour MO = Maintain Only
NR = Not Recommended
Find your battery’s rating on the following
chart, and note the charge time given for
each charger setting. The times given are
for batteries with a 50% charge prior to
recharging. Add more time for severely
discharged batteries.
BATTERY SIZE/RATING
CHARGE RATE / CHARGING TIME
2 AMP 10 AMP 15 AMP
SMALL
BATTERIES
Motorcycle,
garden tractor,
etc.
6-12 Ah 2-3¾ hrs NR NR
12-32 Ah 3¾-10 hrs NR NR
CARS/TRUCKS
200-315 CCA 36-46 Ah 11¼-14½ hrs 2¼ -3 hrs 1½ -2 hrs
315-550 CCA 46-58 Ah MO 3-3¾ hrs 2-2½ hrs
550-1000 CCA 58-111 Ah MO 3¾-7 hrs 2½-4¾ hrs
MARINE/DEEP-CYCLE
56 Ah MO 3½ hrs 2¼ hrs
86 Ah MO 5½ hrs 3½ hrs
96 Ah MO 6 hrs 4 hrs
106 Ah MO 6¾ hrs 4½ hrs
11. MAINTENANCE INSTRUCTIONS
11.1 Cleaning and user maintenance should not
be done by children without supervision.
11.2 After use and before performing
maintenance, unplug and disconnect the
battery charger (see sections 5, 6 and 7).
11.3 Use a dry cloth to wipe all battery corrosion
and other dirt or oil from the battery clips,
cords and the charger case.
11.4 Ensure that all of the charger components
are in place and in good working condition,
for example, the plastic boots on the
battery clips.
11.5 Servicing does not require opening the unit,
as there are no user-serviceable parts.
11.6 All other servicing should be performed by
qualied service personnel.
11.7 If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualied persons, in order
to avoid a hazard.
