HD PVR Viewer’s Guide – UEC Page 56 of 62
Rear Panel Connectors
4 Satellite inputs including SatCR Female F-Type
Remodulator RF in and RF out Female F-Type, includes XtraView capability
Baseband Video RCA, Yellow
Stereo Audio 2 x RCA, Red / White – Fixed or Variable Volume
(software selectable)
YPbPr 3 x RCA, Yellow, White, Red – YPbPr or Scart RGB
(software selectable)
TV Scart CVBS out or S-Video out or RGB out (software
selectable), Audio
Power Cable Connector Figure 8 socket
Digital Audio Optical Toslink, RCA, Orange
S-Video MINI DIN
General
Front Panel Buttons 14 Functions
Front Panel LEDs 4
Main Voltage 170 – 250 VAC, 47 – 63 Hz
RCU Infra Red
Front Panel USB Behind the door
Front Panel Smartcard reader Behind the door
HD PVR Viewer’s Guide UEC Version 2 (Dec 2008) e&oe
