Dtronic Q-2Plus - Connecting Pads and Module; Connection Safety Caution

7
Part 1: Assembly instruction
Connect the pads with the module by using the cables which are labelled with the according pad and jack label. The figure shows
the positions and names of the pads.
Q-2plus
with RIDE
with CRASH
with HH
with TOM1
with TOM2
with TOM3
with KICK
with HHC
with SNARE
Connecting the pads to the drum-module
CAUTION!
To prevent electric shock and damage to the devices, make sure the power is switched OFF on the drum module and all
related devices before making any connection.
Connect the pads to the module by using the cables which are labelled with the according pad and jack label. The figure shows the
positions and names of the pads.
