14
List of audio indications and warnings.
One continuous beep - PCB is damage, replace PCB.
One 1.5 second beep - “Party mode” has been activated.
One 2 second beep - Factory defaults have been set.
One 2 second beep - Beams are incorrectly wired or faulty when programming the motor.
or Runtime was aborted for whatever reason.
One 3 second beep - Holiday lockout mode has been activated.
One 3 second beep - Gate triggered when motor is in 3 minute overload lockout.
Two 400 ms beeps - Run time programming (calibrating) has been successful.
Two 1 second beeps - Pedestrian mode was activated.
or No AC power is present, running battery power only.
Three 200ms beeps - Battery power is too low, or
Override function is open or faulty.
Four 100ms beeps - Motor is in holiday lockout.
Four 200ms beeps - Check motor/load fuse (25amp).
- Check motor brushes and armature.
- PCB reader not picking up Magnet on motor.
Five 1 second beeps - Holiday lockout mode has been de-activated.
Twenty 100ms beeps - Motor has stalled or overloaded, then check the following points:
1) Gate pulling force (should not exceed 15kg)
2) Load pot is set too low (Turn pot completely clockwise)
3) Battery voltage under load (Should not drop more than 1 volt)
4) Gearbox gearwheel.
List of LED indications.
FOR SAFETY REASONS.
Infra red beams are recommended for
all gate motor installations.
LED ON when open limit is activated. (
- LED OFF when close limit is activated. (Gate closed).
- LED flashing SLOW (1 sec. on/1 sec. off) (gate is in motion).
- LED flashes 2 long/3 short continuously (gate is stopped midway).
- LED flashes fast (250ms on/250ms off) continuously. (Gate in overload).
- LED flashes 3 fast flashes every 1.5 seconds. (Battery low, <11VDC).
- LED flashes 1 slow/2 fast continuously. (NO 220 VAC power present).
