Dual ALB10 User Manual

6
Main Power Connections
ConnectBAT+,GNDandREMwiresaccordingly.AsuitablefuseMUSTbeinstalledonthe
BAT+leadwithin18"ofthebatteryforprotectionofthevehicle’selectricalsystem.
BATTERY
HIGH LEVEL INPUT
(SPEAKER WIRE)
18”
MAXIMUM
Fuse Rating
Whenreplacingthefuse,makesure
new fuse is the correct type and
amperage.Usinganincorrectfuse
could damage the amplifier. The
ALB10uses(1)15 amp ATO style fuse.
Power/Ground Wire Size
Foroptimumperformance,useonly
12 gaugewireorlarger.Makesure
to use the same size power and
ground wire.
Typical Wire Routing
INSTALLATION
High Level Input (Speaker Wire)
High level inputs should only be used when RCA outputs
are not available from the head unit.Connectthehead
unitspeakeroutputstothehighlevelinputconnector
asshownbelow.Theblackwire(signalreference
ground)mayormaynotrequireaconnectiontochassis
ground - depending on your particular installation. Do
not use both low and high level inputs at the same time.
Connect only one or the other.
HI-LEVEL INPUT CONNECTION
Grey = Right (+)
Grey/Black = Right (-)
Black
= Ground
White/Black = Left (-)
White = Left (+)
