Dual CS 429 User Manual

17
Product overview
Nr
Description
1
Dust cover hinges (2×)
2
Platter
3
Platter mat
4
Platter bearing
5
PHONO / LINE Switch
Phono-preamp on-/off
6
RCA-Audio-Output R / L
red - right channel, white - left channel
7
GND: Ground connection
8
Power switch
ON / OFF
9
DC IN: 12 V-Input for Power supply
10
Start / Stop buttons
11
Speed selector
33, 45, 78
12
Tonearm
13
Counterweight
14
Tracking force dial
15
Tonearm lift
16
Tonearm rest with safety fasterner
17
Anti-Skating-Adjustment
18
Tonearm lift lever
19
Lever record size
17, 30
20
Tonearm
21
Union nut
22
Headshell
5
6
7
15
9
14
13
12
8
16
17
18
20
21
22
11
1
2
3
4
10
19

Dual CS 429 Specifications

General

Drive System	Belt Drive
Speeds	33 1/3, 45 RPM
Stylus	Elliptical
Auto-Stop	Yes
Motor	DC Motor
Overhang	19 mm
Tracking Force Adjustment Range	0-4 g
Frequency Response	20 Hz - 20 kHz
Platter	Aluminum
Tonearm	Static Balanced
Phono Preamp	Built-in
