7
INSTALLATION
Typical Wire Routing
DA10004D
Fuse Rating
When replacing fuses, make sure new fuse
is the correct type and amperage. Using an
incorrect fuse could damage the amplifier.
DA6002D - 25A
DA10004D - 25Ax2
Power/Ground Wire Size
For optimum performance, use only the wire
size listed below or larger. Make sure to use
the same size power and ground wire.
DA6002D - 8 awg
DA10004D - 8 awg
