11
CONTROL PANEL FUNCTIONS
• Only operate generator on a level surface.
• Always connect the nut and ground terminal on the frame to an appropriate ground source.
Generator must be properly grounded to prevent electrocution.
ENGINE
MOTEUR
Battery Switch
When starting the generator, turn on the switch and turn off the switch when not in use.
Push Button Start/Stop
When the battery switch is on, long press to automatically start the generator, and
press again to stop the generator.
Ground Terminal
The generator’s ground terminal must always be used to connect the
generator to a driven ground rod. Connect the ground terminal to the
driven ground rod with a No 8 AWG (American Wire Gage) copper
wire. The wire connects to the terminal between the lock washer and
nut. Tighten the nut securely to ensure good connection. Grounding
the generator protects you from electric shock that results from a build
up of static electricity or undetected ground faults.
NEUTRALBONOEOTOFRAME
