Terminal 6 - 230 Vac motor M2 Power supply common

Note

: connect the capacitor of the motor M2 between terminals 4 and 5

Terminal 7 - 230 Vac blinker power supply phase

Terminal 8 - 230 Vac blinker power supply neutral

Terminal board J5

Terminal 1 –

Electric lock 12 Vac power supply (common)

Terminal 2 – Electric lock 12 Vac power supply

Terminal 3 – 24 Vac power supply for photo-cells or other devices (common)

Terminal 4 – 24 Vac power supply for photo-cells or other devices

Terminal 5 –

Common Terminal for all electric contacts of commands or security devices

Terminal 6 – Photoelectric cell’s normally closed electric contact (photostop)

Terminal 7 – Photo-cell’s normally closed electric contact

Terminal 8 –

Emergency push-button’s normally closed electric contact (stop)

Terminal 9 – Pedestrian start push-button’s normally open electric contact

Terminal 10 – Start push-button’s normally open electric contact

Important

: The normally closed inputs not in use must be fitted with jumpers

Terminal board J4

Terminal 1

–

Courtesy light’s 230 Vac power supply phase

Terminal 2 – Courtesy light’s 230 Vac power supply neutral

Terminal 3 – Open-gate lamp‘s 230 Vac power supply phase

Terminal 4

Open-gate lamp‘s 230 Vac power supply neutral

Terminal board J1

Terminal 1 –

Aerial cable connection (signal) for radio receiver card

Terminal 2 – Aerial cable connection (shield) for radio receiver card

Terminal board J7

Terminal 1 – Ground cable connection

Terminal 2 - 230 Vac mains power supply phase

Terminal 3 -

230 Vac mains power supply neutral

Connector J2

Terminal 1 – Normally open electric contact connected to the start

Terminal 2

– Common of the normally open electric contact connected to the start

Terminal 3 – Normally open electric contact connected to the pedestrian start

Terminal 4 – Common of the normally open electric contact connected to the pedestrian start

Terminal 5 -

12 Vdc power supply negative (common)
