Refit the right-hand tank cover (6), inserting the tabs
(A) in the corresponding slots (B) in the rear cover.
Note
Insert the lugs (O) under the front tank cover (3).
Repeat the above operations to refit the left-hand
tank cover.
Insert the screws (1) and (2) in the front tank cover
(3), starting with the front screws (1).
B
A
6
3
O
Fig. 101
3
1
1
2
Fig. 102
