E
30
Front brake lever (fig. 20)
Pull in the lever (1) towards the twistgrip to operate the
front brake. The system is hydraulically operated and you
just need to pull the lever gently.
The control lever features a dial adjuster (2) for lever
distance from the twistgrip on handlebar.
To adjust, keep lever (1) completely extended, turn knob
(2) and set it to one of the four available positions.
Consider that:
position no. 1 corresponds to the maximum distance
between lever and twistgrip, while position no. 4
corresponds to the minimum distance.
Warning
Front brake lever adjustment is to be carried out
when the bike is stopped.
1
fig. 20
2
3
4
1
2
