MAIN COMPONENTS AND DEVICES
Location (fig. 24)
1) Tank filler plug.
2) Pillion seat catch and helmet hooks.
3) Glove compartment catch.
4) Side stand.
5) Front fork adjusters.
6) Rear shock absorber adjusters.
7) Rear-view mirrors.
8) Silencer and exhaust pipes.
9) Catalyser (not on USA version).
Warning
The exhaust system can be hot even after engine has
been turned off; be careful not to touch the exhaust
system with any part of your body and do not park the
vehicle next to flammable material (such as wood, leaves
and so on).
48
8
6
7
8
7
1
9
5
5
5
3 6 2
fig. 24
