Ducati Multistrada 1000ds - Rear Brake Pedal; Gear Change Pedal

E
31
Rear brake pedal (fig. 21)
Push down on the pedal (1) to apply the rear brake. The
system is hydraulically operated and therfore only a
minium pressure is required.
Gear change pedal (fig. 22)
Gearchange pedal features a center rest position N, with
automatic return; this condition is signalled by the pilot
light N (8, fig. 5) on the instrument panel turning on.
The pedal can be moved:
down = push down on the pedal to engage 1st gear and to
shift down. The N light will go out.
up = lift the pedal to engage the 2nd gear and then the 3rd,
4th, 5th and 6th gear.
Each time you move the pedal you will engage the next
gear.
1
fig. 21
N
1
2
3
4
5
6
fig. 22
