E
92
Wiring Colour Coding
B Blue
W White
V Violet
Bk Black
Y Yellow
R Red
Lb Light Blue
Gr Gray
G Green
Bn Brown
O Orange
P Pink
Note
The system wiring diagram is at the end of this
manual.
Legend of fuse box
Pos. El.items Rat.
A Key-on 7.5A
B Lights 15A
C Horn,stop,solenoid
starter,passing
20A
DNQS 3A
EGrip Heating 5A
F Injection 20A
G ECU power supply 3A
H Side stand switch 3A
