 menu - information (Info)
This Function allows viewing the vehicle 
voltage and the RPM "digital" indication.
Enter the  menu (SETTING MENU).
Select "Info" option, by pressing  (1) or (2).
Once function is highlighted, press  (4).
When entering this function, the instrument panel
displays:
-  with  voltage value;
- "rpm" with the number of engine rpm in digital
format.
To exit the menu and go back to previous page
highlight the "
Back" indication and press 
(4).
 information is displayed as follows:
- if the  voltage is equal to or lower than
10.9 V, the "LOW" message will be displayed in
red and flashing;
- if  voltage is between 11.0 V and 11.7 V the
reading will be displayed in red and flashing;
- if  voltage is between 11.8 V and 14.9 V
the reading will be displayed steadily with the
 icon on a standard background;
DRL
Turn indicators
Info
Exit
42
1
Fig 151
Battery
rpm
14,3 volt
15.000
...
Back
42
1
Fig 152
197
