Ducati Panigale V4 R User Manual

5
th
gear 30/22
6
th
gear 30/24
Drive chain from gearbox to rear wheel.
Make: REGINA 135ZRDK
Links: 114

The above gear ratios are the homologated
ones and under no circumstances must they be
modified.
However, if you wish to tune up your motorcycle for
competitions or special tracks, Ducati Motor Holding
S.p.A. will be pleased to provide information about
the special ratios available. Contact a Ducati Dealer
or Authorised Service Centre.

If the rear sprocket needs replacing, contact a
Ducati Dealer or authorised Service Centre.
Incorrect replacement of this component could
seriously compromise your safety and cause
irreparable damage to the motorcycle.
Frame
“Front frame” in aluminium alloy with improved

Aluminium alloy rear subframe.
Steering head angle: 24.2°
Steering angle: 25° LH side / 25° RH side
Trail: 99.7 mm (3.93 in).
Wheels
Front
3-spoke, aluminium alloy forged rim.
Size: MT3.50x17"
Rear
3-spoke, aluminium alloy forged rim.
Size: MT6.00x17"
Tyres
Front
Pirelli Diablo Supercorsa SP "tubeless" radial type.
Size: 120/70-ZR17.
Rear
Pirelli Diablo Supercorsa SP "tubeless" radial type.
Size: 200/60-ZR17.
352

Ducati Panigale V4 R Specifications

General

Power	221 hp (162 kW) @ 15, 250 rpm
Transmission	6-speed with Ducati Quick Shift (DQS) up/down EVO 2
Frame	Aluminum alloy Front Frame
Rear Brake	245 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	200/60 ZR17
Warranty	24 months unlimited mileage
Maintenance Service Intervals	12, 000 km (7, 500 miles) / 12 months
Valve Clearance Check	24, 000 km (15, 000 miles)
Engine Type	4 valves per cylinder
Torque	83 lb-ft (112 Nm) @ 11, 500 rpm
Fuel Capacity	4.23 US gal (16.0 l)
Brakes	245mm disc
Front Suspension	Ohlins NPX 25/30 pressurized fork with TiN treatment, fully adjustable
Rear Suspension	Ohlins TTX36 shock, fully adjustable
Front Brake	Dual 330mm semi-floating discs, radially mounted Brembo Monobloc Stylema® (M4.30) 4-piston calipers
Wheels	Forged aluminum wheels
Safety Equipment	Ducati Traction Control (DTC), Ducati Slide Control (DSC), Ducati Wheelie Control (DWC), Engine Brake Control (EBC), Cornering ABS EVO
Standard Equipment	Ducati Power Launch (DPL), Ducati Quick Shift (DQS) up/down
Instrumentation	TFT color display
