Function menu
From the main screen, press  (1) or (2) on LH
switch to scroll through Function Menu.
Whenever  (1) is pressed, instrument panel
will increase the "position" (from first position to last
position, and back to the first one). Whenever 
(2) is pressed, instrument panel will decrease the
"position" (from last position to first position, and
back to the last one).
In Function Menu box, on the LH side, are the UP
and DOWN arrows - corresponding to
 (1) and  (2) on LH switch - indicating
the chance to scroll through the functions. The
empty circle symbol
is displayed when it is
possible to interact with the displayed function by
pressing  (4) on LH switch, for instance to
reset trip meter 1 (TRIP 1).
Based on the set Info Mode and Riding Mode, the
Function Menu can display  functions.
All functions available in the Function Menu are:
- Odometer (TOT)
- Trip meter 1 (TRIP 1)
- Average Fuel Consumption (CONS. AVG 1)
- Average speed (SPEED AVG 1)
- Trip time (TRIP 1 TIME)
- Ambient air temperature (T AIR)
-  fuel reserve counter (TRIP FUEL)
- Trip meter 2 (TRIP 2)
- Instantaneous fuel consumption (CONS. I.)
- Lap time disabling/enabling (LAP  / On)
visible in TRACK info mode only
- Music player management (PLAYER)
only if Bluetooth module is available and a
 is connected; visible in ROAD info
mode only
Lap Off
0
11:34
A.M.
RACE
RPM X 1000
Gear
km/h
N
11
12
13
14
15
16
17
10
9
5
6
7
8
4
3
2
1
DTC 2
DQS OFF
DWC 8
SETTING MENU
TRIP 1
TOT km
1245
0.0 km
LO HI
4
1
2
Fig 27
85

Ducati Panigale V4 R Specifications

General

Power	221 hp (162 kW) @ 15, 250 rpm
Transmission	6-speed with Ducati Quick Shift (DQS) up/down EVO 2
Frame	Aluminum alloy Front Frame
Rear Brake	245 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	200/60 ZR17
Warranty	24 months unlimited mileage
Maintenance Service Intervals	12, 000 km (7, 500 miles) / 12 months
Valve Clearance Check	24, 000 km (15, 000 miles)
Engine Type	4 valves per cylinder
Torque	83 lb-ft (112 Nm) @ 11, 500 rpm
Fuel Capacity	4.23 US gal (16.0 l)
Brakes	245mm disc
Front Suspension	Ohlins NPX 25/30 pressurized fork with TiN treatment, fully adjustable
Rear Suspension	Ohlins TTX36 shock, fully adjustable
Front Brake	Dual 330mm semi-floating discs, radially mounted Brembo Monobloc Stylema® (M4.30) 4-piston calipers
Wheels	Forged aluminum wheels
Safety Equipment	Ducati Traction Control (DTC), Ducati Slide Control (DSC), Ducati Wheelie Control (DWC), Engine Brake Control (EBC), Cornering ABS EVO
Standard Equipment	Ducati Power Launch (DPL), Ducati Quick Shift (DQS) up/down
Instrumentation	TFT color display
