Instrument panel
(Dashboard)
Instrument panel
1) DISPLAY
2) NEUTRAL LIGHT N (GREEN)
Comes on when in neutral position.
3) GENERIC ERROR WARNING LIGHT
(AMBER
YELLOW)
It turns on when there are any "vehicle" errors, i.e.
active errors triggered by any control unit other than
the engine control unit.
4) HIGH BEAM LIGHT
(BLUE)
It turns on to indicate that the high beam lights are
on and when the flasher is activated.
5) FUEL WARNING LIGHT
(AMBER YELLOW)
Comes on when fuel is low (see chapter “Top-ups”).
6) TURN INDICATOR LIGHTS
(GREEN)
Illuminates and flashes when the turn indicator is in
operation.
7) ENGINE OIL PRESSURE LIGHT (RED)
Comes on when engine oil pressure is too low. It
must turn on at "KEY-ON", but must turn  a few
seconds  the engine has  It may 
come on when the engine is hot, however, it should
go out as the engine revs up.

If the ENGINE OIL light stays ON, stop the
engine or it may  severe damage.
8) DAVC LIGHT (AMBER YELLOW)
This light indicates DTC/DWC/DSC system
enabling/disabling status.
- Light  DTC/DWC/DSC enabled and
functioning;
- Light ON flashing: DTC/DWC/DSC enabled, but
with degraded 
- Light steady ON: DTC/DWC/DSC disabled and/
or not functioning due to a fault in the control
unit.
9) ENGINE DIAGNOSIS - MIL LIGHT
(AMBER
YELLOW)
