Ducati Panigale V4 R User Manual

Hazard function (4 turn indicators)
The "Hazard" function turns all four turn indicators
on at the same time to signal an emergency
condition. Push  (11) to activate the "Hazard"
function. It can only be activated when vehicle is
turned on (Key-ON). When the "Hazard" function is
active, all four turn indicators blink at the same time
as well as warning lights on the instrument panel.
The "Hazard" function can be manually turned 
exclusively when vehicle is on (Key-ON), by pressing
 (11).
Once the "Hazard" function is activated, if vehicle is
turned  (key turned to "OFF"), the function stays
active for 2 hours.  2 hours, the turn indicators
switch OFF automatically in order to save 
charge.
Note
If user  a Key-ON while the "Hazard"
function is still active, the function will remain ON
(temporary turn indicator control interruption is
allowed during the instrument panel initial check
routine).
11
Fig 188
0
11:34
A.M.
RACE
RPM X 1000
Gear
km/h
N
11
12
13
14
15
16
17
10
9
5
6
7
8
4
3
2
1
DTC 2
DQS OFF
DWC 8
SETTING MENU
TRIP 1
TOT km
1245
0.0 km
LO HI
Fig 189
238

Ducati Panigale V4 R Specifications

General

Power	221 hp (162 kW) @ 15, 250 rpm
Transmission	6-speed with Ducati Quick Shift (DQS) up/down EVO 2
Frame	Aluminum alloy Front Frame
Rear Brake	245 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	200/60 ZR17
Warranty	24 months unlimited mileage
Maintenance Service Intervals	12, 000 km (7, 500 miles) / 12 months
Valve Clearance Check	24, 000 km (15, 000 miles)
Engine Type	4 valves per cylinder
Torque	83 lb-ft (112 Nm) @ 11, 500 rpm
Fuel Capacity	4.23 US gal (16.0 l)
Brakes	245mm disc
Front Suspension	Ohlins NPX 25/30 pressurized fork with TiN treatment, fully adjustable
Rear Suspension	Ohlins TTX36 shock, fully adjustable
Front Brake	Dual 330mm semi-floating discs, radially mounted Brembo Monobloc Stylema® (M4.30) 4-piston calipers
Wheels	Forged aluminum wheels
Safety Equipment	Ducati Traction Control (DTC), Ducati Slide Control (DSC), Ducati Wheelie Control (DWC), Engine Brake Control (EBC), Cornering ABS EVO
Standard Equipment	Ducati Power Launch (DPL), Ducati Quick Shift (DQS) up/down
Instrumentation	TFT color display
