Ducati Panigale V4 R - Main components and devices; Position on the vehicle

Rear brake pedal
Loosen lock nut (7).
Turn pedal stroke adjusting screw (6) until pedal is in
the desired position. Tighten the lock nut (7).
Operate the pedal (8) by hand to check that there is
1.5 to 2 mm (0.06÷0.09 in) of free play before the
brake bites.
If not, adjust the length of the master cylinder
pushrod.

Have the pedal adjusted at a Ducati Dealer or
authorised Service Centre.
6 7
Fig 210
6 8
7
Fig 211
260
