Note
This is the procedure specified by Italian
regulations for checking the maximum height of the
light beam. Please adapt said procedure to the
provisions in force in your own country.
To align the headlight beam, turn the screws (1) and
(2) located at the front of the vehicle, on both sides.
Screw (1), positioned on the  side, acts on the high
beam:
- turn clockwise to lower the light beam;
- turn counter clockwise to raise the light beam.
Screw (2), positioned on the right side, acts on the
low beam:
- turn clockwise to lower the light beam;
- turn counter clockwise to raise the light beam.
2
1
Fig 264
21
Fig 265
324

Ducati Panigale V4 R Specifications

General

Power	221 hp (162 kW) @ 15, 250 rpm
Transmission	6-speed with Ducati Quick Shift (DQS) up/down EVO 2
Frame	Aluminum alloy Front Frame
Rear Brake	245 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	200/60 ZR17
Warranty	24 months unlimited mileage
Maintenance Service Intervals	12, 000 km (7, 500 miles) / 12 months
Valve Clearance Check	24, 000 km (15, 000 miles)
Engine Type	4 valves per cylinder
Torque	83 lb-ft (112 Nm) @ 11, 500 rpm
Fuel Capacity	4.23 US gal (16.0 l)
Brakes	245mm disc
Front Suspension	Ohlins NPX 25/30 pressurized fork with TiN treatment, fully adjustable
Rear Suspension	Ohlins TTX36 shock, fully adjustable
Front Brake	Dual 330mm semi-floating discs, radially mounted Brembo Monobloc Stylema® (M4.30) 4-piston calipers
Wheels	Forged aluminum wheels
Safety Equipment	Ducati Traction Control (DTC), Ducati Slide Control (DSC), Ducati Wheelie Control (DWC), Engine Brake Control (EBC), Cornering ABS EVO
Standard Equipment	Ducati Power Launch (DPL), Ducati Quick Shift (DQS) up/down
Instrumentation	TFT color display
