Tips on how to select the sensitivity level

Excellent operation of the DTC system, for all
available levels, is ensured only with OE tyres and/or
with the ones recommended by Ducati and with the
OE final drive ratio. In  OE tyres for this
motorcycle are Pirelli Diablo Supercorsa SP in the
following sizes: 120/70ZR17 at the front,
200/60ZR17 at the rear. The use of tyres of 
size and characteristics to the original tyres may alter
the operating characteristics of the system thus
making it unsafe. It is recommended not to install
tyres of  size than the ones approved for
your vehicle.
As far as tyres are concerned, in the case of minor
 such as, for example, tyres of a 
make and/or model than the OE ones, it is necessary
to use the relevant automatic calibration function in
order to restore correct system operation.
As far as the final ratio is concerned, when using a
 ratio (which only possible for tracing use)
than the original equipment one, it is recommended
to use the relevant automatic calibration function in
order to restore optimal system operation.
If level 8 is selected, the DTC will kick in at the
slightest hint that the rear wheel is  to spin.
Between level 8 and level 1 there are other 6
intermediate levels. DTC intervention gradually
decreases from level 8 to level 1.
Level 1 is specifically designed for track use with SC1
compound tyres (Pirelli Diablo Supercorsa SC1) that
are not the OE ones for this motorcycle. The use of
this level with tyres having  characteristics
may alter the operating characteristics of the
system.
The choice of the correct level depends on 3 main
variables:
1) The grip (type of tyre, amount of tyre wear, the
road/track  weather conditions, etc.)
2) The characteristics of the path/circuit (bends all
taken at similar speeds or at very 
speeds)
3) The riding mode (whether the rider has a
"smooth" or a "rough" style)
Level depends on grip conditions
60

Ducati Panigale V4 R Specifications

General

Power	221 hp (162 kW) @ 15, 250 rpm
Transmission	6-speed with Ducati Quick Shift (DQS) up/down EVO 2
Frame	Aluminum alloy Front Frame
Rear Brake	245 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	200/60 ZR17
Warranty	24 months unlimited mileage
Maintenance Service Intervals	12, 000 km (7, 500 miles) / 12 months
Valve Clearance Check	24, 000 km (15, 000 miles)
Engine Type	4 valves per cylinder
Torque	83 lb-ft (112 Nm) @ 11, 500 rpm
Fuel Capacity	4.23 US gal (16.0 l)
Brakes	245mm disc
Front Suspension	Ohlins NPX 25/30 pressurized fork with TiN treatment, fully adjustable
Rear Suspension	Ohlins TTX36 shock, fully adjustable
Front Brake	Dual 330mm semi-floating discs, radially mounted Brembo Monobloc Stylema® (M4.30) 4-piston calipers
Wheels	Forged aluminum wheels
Safety Equipment	Ducati Traction Control (DTC), Ducati Slide Control (DSC), Ducati Wheelie Control (DWC), Engine Brake Control (EBC), Cornering ABS EVO
Standard Equipment	Ducati Power Launch (DPL), Ducati Quick Shift (DQS) up/down
Instrumentation	TFT color display
