6.3.2 Altering parameter values
A operator level parameter values are changed with the four program buttons ("
G
", "
F
",
"
+
", "
-
") on the right-hand side of the operating panel.
The parameter list on the next page gives all parameters which can be altered at
operator level.
1. Selecting programming mode
-
Turn on the main switch.
"
MANUAL
" appears in the display.
-
Press and hold down the "
G
" button.
-
Press the "
-
" button.
"
- - - - - - >F
" appears in the display.
-
Release both buttons.
The control unit is in programming mode.
NB:
The sewing drive is inoperative in programming mode.
2. Selecting parameter number
-
Press the "
G
" button.
The button must be pressed repeatedly until the group number (e.g. 6xx) appears.
-
Press the "
F
" button repeatedly until the required parameter number appears in
the display (e.g. "
102*0002
").
If the "
F
" button is held down the parameter number continues to change until it is
released.
3. Changing the displayed parameter value
-
-
Use the "
+
" and "
-
" buttons to increase or reduce the parameter value.
If the "
+
" or "
-
" button is held down the parameter number continues to change un-
til it is released.
-
If you leave the parameter-number routine the last-displayed parameter value is
automatically saved.
4. Leaving programming mode
-
Simultaneously press the "
G
" and "
-
" buttons.
The control unit leaves programming mode.
The last-displayed parameter value is saved.
-
"
MANUAL
" appears in the display.
-
The control unit is ready for use.
The new settings can be checked by executing a test seam.
