Duevi PEPEROSSO - Jumpers; Buttons; Leds; Tamper

15
CN11
NOT USED
CN12
NOT USED
BAT
Battery connector 12 V / 0,8 Ah
JUMPERS
OFF
ON
JP1
Anti-opening Tamper active
Anti-opening Tamper deactivate
JP2
Anti-removal Tamper active
Anti-removal Tamper deactivate
BUTTONS
K1
Plunger return button (after nebulisation)
Allow to – after nebulisation occurred – rearm the device
LEDS
OFF
ON
LED
Normal functioning
Battery poles inverted
Tamper
In case of cover removing the tamper line through T1-T2 terminals is opened.
