Duevi PEPEROSSO - Installation

7
Installation
To open the cover unscrew the screws at both sides of the device (fig. 1).
Screw
Screw
Cover
Nebulisation
windows
Motor base
Screw for
motor base
Anti-opening
tamper
Screw for
motor base
CN1
connector
(removable)
Space for spray
cans
Anti-removing
tamper
Battery
compartment
Electronic
board
Anti-opening
tamper
Wall
mounting
hole
Wall
mounting
hole
Wall mounting
hole
Cable path
Screw for
motor base
Fig. 1
Fig. 2
Fig. 3
Fig. 4
