Duevi PEPEROSSO - Stand-Alone Mode

19
Stand-alone mode
Principle diagram for use of Peperosso in stand-alone mode (no control panel required).
Note: it’s necessary to connect the detector as in scheme on page 11
Peperosso
Must be powered with
12 V
Detector
Connect to Peperosso
on IN3 as confirm
Hardware key
Close IN1 and IN2
towards +12 V
disabling Peperosso
