7. Charging and power system diagram
Labe
l
Description
A
Windlass*
B
Windlass remote control*
C
D
Remote control relay*
8A fuse: engine test
E
Charger*
F
12V distribution panel
G
Single-pole 110A circuit breaker*
H Auxiliary batteries (1 as std + 2 as option*)
I
125A fuse (auxiliary)
J
House batteries switch
K
5A fuse*
L Alternator
M
Distributor
N
Starter
O
Engine battery
P Engine battery isolator
Q
Windlass relay*
R
Bilge fan relay
S
5A fuse
T Bilge fan
B-
-ve terminal (electrical panel)
B+
+ve terminal (electrical panel)
*
