Dufour 412 - Freshwater System Layout Diagram

68/82
16. Freshwater system diagram
Labe
l
Description
1
Filler deck plate
2
Filler hose
3
Vent
4
Vent hose
5
6
Fore water tank, 160 L
Stern water tank 200 L
7
Hot water pipe
8
Cold water pipe
9
Pressurized water pump unit
10
Freshwater pump
11
Water heater
12
Bathroom mixer tap – shower head
13
Galley single-lever mixer tap
14
Deck shower
15
Bathroom mixer tap
16
1/2" 2-way manifold
17
¾" M plug
18
½" ¼-turn FF seacock (x2)
19
¾" F connector
20
21
22
23
24
24
½" M connector (x2)
Freshwater/seawater cock
Plug: Optional fore dressing table
Sea water foot pump
Toilet seawater intake*
Foldaway mixer tap*
*
Option
