Dufour 412 - Skin Fitting Location Diagram

72/82
18. Skin fitting location diagram
Labe
l
Description
Ø -inch
Skin-fittings + seacocks
1
Galley sink discharge
1"
2
Wash-basin/shower outlet
1"
3
4
Toilet seawater intake
Toilet discharge
3/4"
1-1/2"
5
6
7
12
Dressing table sink discharge*
Foot pump seawater intake
Anchor locker discharge (x2)
Air-conditioning discharge* (x3)
3/4"
1/2"
1"
1/2"
Skin-fitting
8
Electric bilge pump discharge
1"
9
10
Manual bilge pump discharge
Cockpit sink discharge*
1"
1"
11
Strainer skin fitting*
Sea-water intake for air-conditioning
(x3)* 1/2"
*
Option
