Dufour 412 - Page 61

60/82
Labe
l
Description
A
B
Zone A - 12V
Strip fuse 500A: optional bow thruster*
Zone B - 12 V
Differential circuit-breaker 110A: windlass*
Blade fuse 30A: inverter protection*
Blade fuse 15A: Refrigeration unit*
Blade fuse 1A: with gas solenoid valve*
Blade fuse 10A: optional bow thruster*
Blade fuse 15A: Exterior fridge*
Blade fuse 40A: with auto-pilot option*
Blade fuse 10A: heating option*
Blade fuse 5A: with windlass option*
C
Blade fuse 5A: with navigation instrument pack option*
Resettable circuit breaker type C 16A: electric toilet*
Zone C - 12V
Strip fuse 160A: panel protection
Blade fuse 10A: bilge fan
Blade fuse 15A: optional automatic bilge pump*
Blade fuse 15A: optional exterior fridge*
D
Zone D - 220V 6-way box
Differential circuit-breaker 16A: air conditioning protection*
Single-pole + neutral circuit breaker: A/C compressor protection (x3)*
E
Zone E - 12V
Differential circuit-breaker 90A: electric halyard winch.*
Differential circuit-breaker 100A: electric genoa winch (x2)*
Single-pole 6A circuit breaker: rear door piston cover*
F
Zone F - 220V
2-pole circuit breaker: shore protection
