Dunham-Bush ACDX - PHYSICAL SPECIFICATIONS

PHYSICAL SPECIFICATIONS
MODEL SIZE 040 050 060 080 095 120
Compressor
Model (Qty) SSCA050 (1) SSCA060 (1) SSCA075 (1) SSCA050 (2) SSCA060 (2) SSCA075 (2)
Displ (CFH)/Compr. 5850 7212 8880 5850 7212 8880
Oil Chg/Compr (Qts.)(Type) 5 3/4(D/B SR 30) 6 3/4(D/B SR30) 6 3/4(D/B SR30) 5 3/4(D/B SR 30) 6 3/4(D/B SR30) 6 3/4(D/B SR30)
% Capacity Reduction 100 - 33% MIN. 100 - 25% MIN. 100 - 25% MIN. 100 - 16.5% MIN. 100 - 12.5% MIN. 100 - 12.5% MIN.
Oil Lubrication PRESSURE PRESSURE PRESSURE PRESSURE PRESSURE PRESSURE
Crank Case Htr Watts/Compr 200 200 200 200 200 200
Air Cooled Condenser
Front Module W-156-316-080 W-156-316-120 W-156-316-120 W-156-316-160 W-156-316-200 W-156-316-240
Rear Module N/A N/A N/A N/A N/A N/A
Fan Dia. (Qty) 30(4) 30(6) 30(6) 30(8) 30(10) 30(12)
Total Fan KW 6.84 6.0 10.26 13.68 17.10 20.52
Motor RPM 1100 1100 1100 1100 1100 1100
DX Cooler (Std)
Model CHSO10601B CHSO11601B CHS013601B EXD14102J09 EXD16112J09 EXD16122J07
Shell Diameter 10 11 13 14 16 16
Nom. Shell Lgth. 60 60 60 102 112 122
Water Conn. In/Out 4" 4" 4" 5" 6" 6"
Connection Type VICTAULIC VICTAULIC VICTAULIC VICTAULIC VICTAULIC VICTAULIC
General
No. of Refrig. Circuits 1 1 1 2 2 2
Refrig. Charge (lbs.)/Circ. 83 103 125 84 104 126
Shipping Weight 3517 4639 4910 7462 9331 10341
Operation Weight 3592 4732 5044 7712 9684 10726
MODEL SIZE 150 170 185 210 235 255
Compressor
Model (Qty) SSCA060 (3) SSCA075(3) SSCA060(4) SSCA075(4)
SSCA060(1), SSCA060(2)
SSCA075(2) SSCA075(2)
Displ (CFH)/Compr. 7212 7212, 8880 8880 7212 7212, 8880 8880
Oil Chg/Compr (Qts.)(Type) 6 3/4(D/B SR30) 6 3/4(D/B SR30) 6 3/4(D/B SR30) 6 3/4(D/B SR30) 6 3/4(D/B SR30) 6 3/4(D/B SR30)
% Capacity Reduction 100 - 8.3% MIN. 100 - 8.3% MIN. 100 - 8.3% MIN. 100 - 6.3% MIN. 100 - 6.3% MIN. 100 - 6.3% MIN.
Oil Lubrication PRESSURE PRESSURE PRESSURE PRESSURE PRESSURE PRESSURE
Crank Case Htr Watts/Compr 200 200 200 200 200 200
Air Cooled Condenser
Front Module W-156-316-200 W-156-316-240 W-156-316-240 W-156-316-200 W-156-316-200 W-156-316-200
Rear Module W-156-316-120 W-156-316-120 W-156-316-120 W-156-316-200 W-156-316-200 W-156-316-200
Fan Dia. (Qty) 30(16) 30(18) 30(18) 30(20) 39(20) 30(20)
Total Fan KW 27.36 30.78 30.78 34.2 34.2 34.2
Motor RPM 1100 1100 1100 1100 1100 1100
DX Cooler (Std)
Model EXT18122J07 EXT18122J07 EXT20122J07 EXF20122J07 EXF20122J07 EXF20122J07
Shell Diameter 18 18 20 20 20 20
Nom. Shell Lgth. 122 122 122 122 122 122
Water Conn. In/Out 8" 8" 10" 10" 10" 10"
Connection Type VICTAULIC VICTAULIC VICTAULIC VICTAULIC VICTAULIC VICTAULIC
General
No. of Refrig. Circuits 3 3 3 4 4 4
Refrig. Charge (lbs.)/Circ. 114 (1) 103 (2) 125 128 106 (2) 106 (2) 128 128
Shipping Weight 14482 15423 16213 17979 18165 18311
Operation Weight 14987 15928 16778 18544 18730 18876
