Part Names and Their Functions
Front cover
Drum handle
Drum unit
Ink pack
Scanner unit
Lever
This lever releases the ink
pack holder.
Lever
This lever is locks or
unlocks the drum.
Master set switch
When the master set switch is pushed,
the master is pulled in and set.
Master roll
Thermal head escape lever
Master holder
