Turrets SMA/SMB*M
Inertia max.
(kgm
2
)
Control Unit HW code Parameter
set
Table Turret
Liv.1 Liv.2
DDC4-15-400/20 0496320* 0489101-4 0 reserved
DDC4-15-400/20 0496320*01 0489101-4 1 Not used
DDC4-15-400/20 0496320*02 0489101-4 2 Not used
DDC4-15-400/20 0496320*03 0489101-4 3 SMA-*-16…..400V 1,2 2,2
DDC4-15-400/20 0496320*04 0489101-4 4 Not used
SMA-*-20…..400V 2,6 5
SM-B 16 2,6
DDC4-15-400/20 0496320*05 0489101-4 5
SM-B 20 5
DDC4-15-400/20 0496320*06 0489101-4 6 SMA-*-20…..400V 5 9
SMA-*-25…..400V 5 9 DDC4-15-400/20 0496320*07 0489101-4 7
SM-B25 9
DDC4-15-400/20 0496320*08 0489101-4 8 SMA-*-25…..400V 9 14
DDC4-15-400/20 0496320*09 0489101-4 9 Not used
DDC4-15-400/20 0496320*10 0489101-4 10 Not used
DDC4-15-400/20 0496320*11 0489101-4 11 Not used
DDC4-15-400/20 0496320*12 0489101-4 12 Not used
DDC4-15-400/20 0496320*13 0489101-4 13 No Not used
DDC4-15-400/20 0496320*14 0489101-4 14 FL-16…400V 1,4 2,5
DDC4-15-400/20 0496320*15 0489101-4 15 Not used
DDC4-15-400/20 0496320*16 0489101-4 16 Not used
*: numbero of tools
A=8/12
B=6/12
C=12/24
D=8/16
E=12/16
F= 5/10
G= 4/8
H= 16/12
The information described in this manual may be subject to variations due to technical modifications.
DUPLOMATIC AUTOMAZIONE S.p.A. reserves the right to modify the contents of this manual without prior notice.
