CHARACTERISTICS OF THE CONTROL UNIT
• Best path research.
• External selection of rotation direction.
• Automatic reference search.
• Parity control on position code.
• Enhanced diagnostic.
• Selection of two ranges of positions (eg. 8 and 12 or 6 and 12) with dedicated inputs.
• Selection of inertia on disc with dedicated input.
• Speed reduction for maintenance purposes with dedicated input.
• 'Safety' behaviour can be set by CNC or PC.
The entire unit is insulated from the external with optoinsulators to satisfy safety standards.
Parameters of the system are optimised and cannot be modified by the customer.
TECHNICAL CARACTERISTICS OF THE CONTROL UNIT
DRIVER SECTION SUPPLY
Power input 3 Φ
400V +15% - 10 %
50/60Hz ±2Hz 3 Φ
18 A max. (DDC4-15-400)
10 A max (DDC4-10-400)
Auxiliary input DC
24V DC±10%
35W
tab 1
Supply for I/O
DC SUPPLY
24V DC±10%
3A max.
Digital inputs
• Type
• Voltage
• Current
Sink
24 VDC ±10%
5 mA @ 24 VDC
Digital outputs
• Type
• Max current for signals
Electrovalve
• Type
• Max current for electrovalve
• Transistor MOS N.O. (Source)
• 0.1 A max (PTC protection + FUSE
F7 protection)
• Relay N.O. (Source)
• 2A max (FUSE F6 protection)
tab 2
General specifications
Operative Temperature
0 ÷ 55 °C
Humidity
30.. 95%
Vibrations
4G RMS (for short period)
0,5 RMS (continuously)
tab 3
