1 Introduction
Throughout this manual, the following symbols will be used to highlight important information and procedures:
WARNING! A dangerous voltage or other
condition exists. Use extreme caution when
performing these tasks.
Function performed by energy
management system / controller.
CAUTION! Th
is information is critical to the safe
installation and or operation of the product.
Follow these instructions closely.
NOTE: This statement is important.
F
ollow instructions closely.
1.1 About this manual – supporting documents
This manual is intended to be used by qualified service and installation personnel for the purposes of installation
and startup only. The DURACELL HUB energy management system & gateway requires installer administration and
device commissioning prior to operation of the ESS. Refer to the Fleet Installer Administration Guide and the
DURACELL HUB Install & Commission Quick Guide for further details.
This product is permanently wired to the home electrical service, and must be installed by a licensed electrician
only. This product is a power distribution peripheral intended to be operated with the ESS. Refer to the DURACELL
POWER CENTER 5KW Installation & Startup Manual for installation of the ESS.
Go to
www.duracellpowercenter.com
for a complete list of installer resource materials.
1.2 Glossary
1.3 Initial Inspection of Material List
Th
e system components supplied with the
DURACELL HUB are shown below. Each
component should be inspected visually for any
damage that may have been caused by
shipment. If parts are missing or damaged,
please contact your local distributor.
Term Definition Term Definition
AC / DC Alternating Current / Direct Current NC/NO Normally Closed / Normally Open
AHJ Authority Having Jurisdiction NEC/CEC National (USA) Electric Code / Canadian Electric Code
ARC Auto Recovery Control PCS Power Control System (Inverter)
DC Direct Current PE (GND) Protective Earth
EMC Energy Management Controller PV Photo-Voltaic
EMS Energy Management System RF Radio Frequency
ESS Energy Storage System SOC State Of Charge (Battery)
LED Light Emitting Diode SOH State of Health (Battery)
Item
Description
1 EMS-A DURACELL HUB
2 Current transformer – 200 Amp
3 Current transformer – 50 Amp
4 EMS to PCS RJ-45 cable
5 AK1 DURACELL HUB control cable
6 USB to Mini-USB service cable
(x2)
: DURACELL HUB materials list.
To Next Page
