SensoWash_MAL_WWC_US_57045/17.03.3
Important information
About the mounting instructions
These mounting instructions come as part of the
Duravit Shower WC and should be read carefully prior to
installation.
Explanation of the key words and symbols
DANGER! At high risk of fatal hazards or serious
injuries
NOTE! To avoid property damage
Link to the Electrical Installation section
Link to the installation information in this
section
Link to the Water Installation section
Inspection (e.g. for scratches)
Inspection to collect water
Do not kink hose
Target Readership and Qualifications
The Shower WC and associated water connection may
only be installed by qualified plumbers. The electrical
installation may only be carried out by qualified electri-
cians.
NOTE!
Local installation regulations, country-specific standards
and the low voltage directives must be observed at all
times.
NOTE!
DO NOT not install the Shower WC in rooms where there
is a danger of frost. The room temperature must not be
less than 39 °F.
Safety instructions
DANGER!
Risk of fatal electric shock.
>Do NOT remove individual Shower WC components.
> If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
Installation Instructions
Please read pre-installation data sheets prior to the
installation. These are available to download on the
Internet at www.duravit.com.
The Shower WC unit installation is described in separate
instructions.
An installation video of the complete shower WC is
available at pro.duravit.com/mounting.
Simply use this
QR code
4
Measuring clearance y (Diagram 4)
7
Installing sound insulation set (Diagram 7)
>if the sound insulation set is included with the
delivery, take z into account in the clearance
between the wall and bolt:
Clearance = z+y+
55
/
64
”.
>Screw the bolt onto the hanger bolt until you
achieve the calculated clearance to the wall.
>Install the sound insulation set.
20
Attaching the ceramics to the wall (Diagram 20)
>Position the ceramics on the wall. Ensure that the
hose is not kinked or trapped.
4
en
