L C P Min Max Preset Unity Description
t 01 54 0 1 0 - Increasing U
mag
when the thread clamp magnet will be driven
0 = No;
1 = Yes
Thread trimmer
t 02 00 50 750 180 rpm Cutting speed
t 02 01 0 1 0 - Pedal position for starting the cutting process.
0 = Position -2;
1 = Position -1
t 02 10 0 359 120 ° on switching angle t 08 12 <= t 02 10 < t 02 11
t 02 11 0 359 245 ° off switching angle t 02 10 < t 02 11 <= t 08 13
t 02 20 0 255 0 ms Delay time for a repeated activation of the Cutting magnet.
t 02 21 0 255 0 ms Delay time for turning the cutting magnet off
Sewing foot lifting
t 03 00 0 1 1 - sewing foot lifting active
0 = No;
1 = Yes
t 03 10 0 255 80 ms Intermediate lag of the machine after switching the sewing
foot lifting off
t 03 11 0 255 40 ms Turn-on delay of the sewing foot lifting at speed 0
t 03 12 0,0 9,999 0,200 s Turn-on delay of the sewing foot lifting at the seam end
t 03 50 0 999 200 ms Drive time of the sewing foot lifting magnet in the time
period t
1
t 03 51 5 100 100 % Pulse duty ratio in the time period t
1
t 03 52 0,0 600,0 60,0 s Drive time of the foot lifting magnet in the time period t
2
(If you adjust 0s the thread clamp magnet will be driven
permanently)
t 03 53 5 100 40 % Pulse duty ratio in the time period t
2
t 03 54 0 1 1 - Increasing U
mag
when the foot lifting magnet will be driven
0 = No;
1 = Yes
Soft start
t 05 00 120 1000 400 rpm Soft start speed
t 05 01 1 99 2 Stitches Number of soft start stitches
Seam ways
t 07 00 0 2 0 - Treatment position-2 in seam ways.
0 = Demolition of the seam. The next seam way is sewn; The
seam is broken off with thread trimmer at the last seam of
the program.
1 = Demolition of the seam with thread performances (even if
inactive). The next seam process is a free seam.
2 = Demolition of the seam with thread performances (even if
inactive). Seam program is stopped.
t 07 01 0 1 0 - Automatic system business.
0 = off;
1 = on
Motor
t 08 00 500 9999 1600 rpm Maximum speed
t 08 01 10 400 150 rpm Minimal speed
t 08 02 10 1000 150 rpm Positioning speed
t 08 03 1 100 20 rpm/ms Acceleration ramp
t 08 04 1 100 20 rpm/ms Braking ramp
t 08 05 0 1 0 - Direction of rotation of the motor
0 = on the left;
1 = on the right
