26
86 GBT16674-B8-40 7
Flange bolt M8h40
97 DJ190F-12002-A 1 Pin, piston
87 DJ188FD-11001-B 1 Crankcase cover 98 DJ190F-12200-B 1 Connecting rod assy.
88 GBT818-S5-10 3
Flange bolt M5h10
99 DJ188FD-15200-A 1 Control assy.
89 DF3800H-11032-A 1 Fan cover 100 DJ188F-15007-A 1 Spring, governor
90 DJ188F-11007-A 1 Cap assy. oil filler 101 DJ188F-15008-A 1 Spring, throttle return
91 DJ188F-15100-A 1 Governor kit 102 DJ188F-15004-B 1 Arm, governor
92 DJ188F-11003-B 1 Packing, case cover 103 DJ188F-15006-A 1 Rod, governor
93 DJ168F-11002-B 1
Pin, dowel, 7h12
104 DJ188F-15005-A 1 Bolt, governor arm
94 DJ190F-12300-A 1 Ping set assy. piston 105 DJ168F-11002-C 1
Pin, dowel, 9h12
95 DJ188F-12003-A 2 Clip, piston pin
